PRÜFTECHNIK ROTALIGN Ultra iS - 2.4 sensALIGN Sensor Functionality

ROTALIGN Ultra iS Shaft handbook
22
To replace the rechargeable batteries, use the provided 2.5 mm allen key [0 0739
1055] to undo the two hex screws that affix the battery to either sensALIGN laser or
sensor.
Used batteries should be disposed of in an environmentally-sound manner!
Used batteries should be disposed of in an environmentall
y
-sound manner!
The position and removal
of sensALIGN rechargeable
battery ALI 4.960 is identical
in both sensALIGN laser
ALI 4.910 and sensALIGN
sensor ALI 4.900.
sensALIGN rechargable
battery ALI 4.960
Hex screw
