PRÜFTECHNIK ROTALIGN Ultra iS User Manual

85
IntelliSWEEP features are available only if ROTALIGN Ultra Advanced Shaft
firmware has been installed and licenced in the ROTALIGN Ultra iS computer. This
is done by acquiring the ROTALIGN Ultra Advanced Shaft firmware certificate
ALI 4.741.
After adjusting the laser beam and initializing sensALIGN sensor as described in sections
4.10 and 4.11 in chapter 4, rotate shafts to take measurement. In IntelliSWEEP, hints
are displayed to guide the user through an error-free measurement. The quality of the
measurement as well as real time coupling values are displayed on the screen.
Measurement quality may be analysed in details via the “Measurement” screen
context menu item ‘Analyse’. While in “IntelliSWEEP Measurement” screen, press
q. The context menu appears. Use the navigation keys to highlight ‘Analyse’ ->
‘Detailed quality’.
Note
IntelliSWEEP
f
eatures are available only i
f
ROTALIGN Ultra Advanced Sha
f
t
fi
rmware has been installed and licenced in the ROTALIGN Ultra iS computer. This
is done by acquiring the ROTALIGN Ultra A
d
v
a
n
ced
S
h
a
f
t
firmw
a
r
e
ce
r
t
ifi
cate
ALI 4.741.
Note that measurement
may be started automati-
cally when the shafts are
rotated or triggered
manually by pressing
e.
This preference may be
set in the “Measurement
options” screen accessed
via the “Measurement”
screen context menu item
‘Measurement options’.
The following intelliSWEEP
features are displayed on
the measurement screen:
1
A rough rotation icon
2
Corresponding hint
3
Measurement quality
4
Real time coupling
results
Measurement can be
analysed only after it has
been stopped. To stop a
measurement, use the
context menu item ‘Stop’
which appears in the
“Measurement” screen
during measurement.
Note that in the Expert
licence version, the
“Measurement” screen
context menu items
‘Measurement mode’ and
‘Measurement options’
are displayed as sub menu
items clustered in the
context menu item ‘Mode/
Options’.
4
1
2
3
3
Measurement modes
