BIT SWITCHES
B404 5-24 SM
Scanner Switch 0C
No FUNCTION COMMENTS
0 Action when an original jam
has occurred while scanning
the original into memory for
memory tx
0: Continues scanning after
recovery
1: Stops scanning and erases
all scanned pages for that job
This bit is only effective when parallel memory tx is
disabled (user parameter 07 - bit 2).
If parallel memory tx is enabled, the machine always
erases the scanned pages when an original jam
occurs. The machine then asks the user to retry
from the first page, even if parallel memory tx is not
actually used.
0: The machine displays a message asking the user
to put the jammed page back into the original stack,
and continues scanning.
The message is displayed for the time period
specified by scanner switch 0E, bit 2.
1: The machine erases all the scanned pages and
asks the user to retry from the first page.
1
to
2
Setting when an original size
cannot be recognized
Bit 2 1 Setting
0 0 Depending on the
copier’s setting
0 1 A5/HLT 3 (LEF)
1 0 A5/HLT 4 (SEF)
1 1 No original
When both bits are set to “0”, the machine
recognizes an original size depending on copier’s
service mode.
3-5 Not used Do not change the settings.
6 Scan width used for a
document set in the ADF when
the width is less than 230 mm.
0: A4 (210 mm),
1: LT (216 mm)
This bit is set at “1” when the country code is set to
the US.
7 Not used Do not change the setting.
