Ricoh P C301W Field Service Manual

6.Troubleshooting
207
SC No.
Type
Error Name/Error Condition/Major Cause/Solution
SC547-
02
D
Zero cross-error (relay contact error)
Zero cross processing executed for 0.5 seconds, but relay shut OFF/ON when
zero cross was not generated even once. The process is done three times.
• Damaged fusion relay (contact open)
• Fusion relay circuit defective
• PSU fuse (24VS) blown
Check if the SC occurs by turning the power OFF then ON. If the SC occurs again,
do the following steps. Check if the SC reoccurs by cycling the power after each
step.
1. Replace the PSU (PCB4).
2. Check the harness connections between the PSU (PCB4) and the EGB
(PCB1).
3. Replace the harnesses between the PSU (PCB4) and the EGB (PCB1).
4. Replace the EGB (PCB1).
SC547-
03
D
Zero cross-error (abnormally low frequency)
Zero cross count processing is executed at 0.5 seconds intervals.
• When the zero-cross count is 45 to 54, the frequency is set to 50 Hz.
• When the zero-cross count is 55 to 65, the frequency is set to 60 Hz.
• For cases other than the above ranges, the frequency is abnormal.
When the frequency abnormality is detected 10 times, and the number of low-
frequency detections is 2 or more out of 10 times.
Frequency is the input power source is unstable.
Check if the SC occurs by turning the power OFF then ON. If the SC occurs again,
do the following steps. Check if the SC reoccurs by cycling the power after each
step.
1. Replace the PSU (PCB4).
2. Check the harness connections between the PSU (PCB4) and the EGB
(PCB1).
3. Replace the harnesses between the PSU (PCB4) and the EGB (PCB1).
4. Replace the EGB (PCB1).
SC No.
Type
Error Name/Error Condition/Major Cause/Solution
SC549-
01
D
Low-temperature detected (Fusing thermopile (TH2))
Measurement is started 60 seconds after turning the fusing lamp ON, and the
fusing thermopile (TH2) has detected -100 °C from the target temperature
continuously for 60 seconds.
SC549-
D
Low-temperature detected (Fusing thermopile (TH2)): Low voltage

Ricoh P C301W Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	256 MB
Built-in processor	-
Sound pressure level (printing)	- dB
Cables included	AC
Included cartridge capacity (black)	1000 pages
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
Weight	25000 g
