Function Variants Filling Scale
Parameter Name Default Required
Setting
Recommended
Setting
Comments
Timeout 0.0
0 sec: Tare memory is not cleared after
feeding
> 0 sec: Tare memory cleared after input
time. Restart only possible after
this time.
Discharge Time 0.0 Maximum discharge time; this time ends if it
goes below the discharge weight.
Taring Yes Yes = Filling with
automatic taring
No = Filling without
automatic taring
Settling time: 0.0
Time that can be set between the main
contact dropping (dribble feed) and
tolerance check
Block 'Single Printout'
Timeout 0.0
0 sec: Print-out without no-motion
state monitoring
1-999 sec: Waiting-time to no-motion
state.
Printing option OFF
'OFF': No data output to the data
processing system and no
balancing
'to data
processing
system':
Data output to the data
processing system after printout
'Balance': Balance before printout
'data
processing
system/bal
ance':
Balance before printout and
output data to the data
processing system after printout
Block 'Print Total'
Timeout
Printing option
0.0
OFF
see above
Block 'Print Balance''
Timeout
Printing option
0.0
OFF
see above
Block 'Analog Source'
Source
Gross This block selects what quantity is issued at
the analog output and how it is scaled.
Some quantities and reference values are:
Source
Dimension for Min/Max
Gross: The scale's dimension
Net: The scale's dimension
dW/dt: The scale's dimension/h
Fieldbus: none; the IEEE value of
the PLS-AIn is issued
Controller
magnitude:
Not available in Opus;
output is set to 0
Setpoint: The scale's dimension
Actual value %: Percent of setpoint
Actual value of
dim:
The scale's dimension
Residual value
%:
Percent of setpoint
Residual value of
dim:
The scale's dimension
Next setpoint The scale's dimension
MIN reference
value
0
MAX reference
value
0
BV-H2313 GB 0630 DISOMAT
®
Opus – Operating Manual
- 100 - © Schenck Process GmbH, Darmstadt
