Normal Mode Functionality in Menu Tree
Menu item Function
35:Print Repeat
In case of printer fault (e.g. paper out, copies required), you can
repeat printing as many times as required.
ATTENTION: Print repeat through repeated pressing of the print
start key is not useful; depending on scale type, other functions can
be triggered which are not desired for print repeat.
36:Print 4
Printing with form format 4
37:Print 5
Printing with form format 5
38:Print 6
Printing with form format 6
39:L.f.T. memory
'paperless' printing into legal-for-trade memory
4.2.4 Fct. 5:SERVICE
Use this group of functions to perform, or check, some settings and perform some
tests without password.
• Set date/time
• Request version number
• Set display type
• Search legal-for-trade memory
• Select home position
• Higher Range
4.2.4.1 Fct. 51:Date/Time
Use function to set the clock in DISOMAT. This makes good sense if a printer is
connected and time data are to be printed on print form, or permanently displayed in
dialog field.
Caution: Since your inputs are not checked semantically, even useless inputs, e.g.
41,22,92 are accepted. So strictly observe given format to prevent malfunctions from
occurring.
Note: If system is powered off, clock continues running for approx. 1 week provided
that system has been operating for minimum 30 hours.
Operating Sequence
After selection of input field, current values are displayed.
You can change date in this field:
51:Date/Time
Date: 12.01.00
Date input uses the format dd.mm.yy (dd=day, mm=month, yy=year).
In case of output, the year appears in 4-digit form.
To change time, go to this input field:
51:Date/time
Time: 17:15:30
Time input uses the format hh:mm:ss (hh=hour, mm=minute, ss=second).
New settings are effective after acknowledgement with [OK] key.
BV-H2313 GB 0630 DISOMAT
®
Opus – Operating Manual
- 32 - © Schenck Process GmbH, Darmstadt
