Setting Mode Setting Using Configuration Password
Data:
432:Interfaces
Data: 8-bitno__
To determine number of data bits and type of parity check, there are the following
possibilities:
8-bit no
Data bits: 8; parity: No
8-bit even
Data bits: 8; parity: Even
7-bit even
Data bits: 7; parity: Even
8-bit odd
Data bits: 8; parity: Odd
7-bit odd
Data bits: 7; parity: Odd
Stop Bits:
432:Interfaces
Stop bits: 1
Select '1' or '2'.
Acknowledge with [OK] key to exit function. Selected interface is configured.
5.3.2.3 Fct. 433:COMMUNICATION
This menu offers the functions for setting communication with external devices.
5.3.2.4 Fct. 4331:EDP
Use menu item to physically assign the EDP interface to one of the existing interface
outputs (S1 to S3).
NOTE: In addition, configure interface using menu item '432:Interfaces'.
If interface assignment produces a conflict with printer or secondary display,
system outputs an event message, e.g. 'M3406:Interface already open'. In
this event, the peripheral instruments have to be assigned differently to the
interfaces.
Before using function, set the following parameters:
Parameter Enter / Select Default
Scale Number
Determines DISOMAT logical
address; must always be included in
message header (also if DISOMAT
operates out of network).
0 ... 255:
0 ... 99 with SCHENCK Standard
Protocol (DDP8672) and 3964R
Protocol;
0 ... 255 with S5/Teleperm M and J-
Bus
0
EDP Interface
Physically assigns EDP interface to
available interface outputs (S1 to
S3). If no EDP system is connected,
select 'Off'.
Off, S1, S2, S3 Off
BV-H2313 GB 0630 DISOMAT
®
Opus – Operating Manual
- 64 - © Schenck Process GmbH, Darmstadt
