Schenck process Disomat Opus User Manual

Function Variants Cargo Scale
6.5.6 Parameters
Table of parameters for the 'Cargo Scale Function Variant'
Parameter Name Default Required
Setting
Recommended
Setting
Comments
Block 'Output 3'
FastComp.High
FastComp.Low
HIGH > LOW
LOW > HIGH
Min. contact
Max. contact
Block 'Output 4'
FastComp.High
FastComp.Low
LOW > HIGH
HIGH > LOW
Max. contact
Min. contact
Block 'Weighing'
Timeout 0.0
0 sec: Print-out without no-motion state
monitoring
1 -999 sec: Waiting-time to no-motion state.
Printing option OFF
'OFF': No data output to the data
processing system and no
balancing
'to data
processing
system':
Data output to the data
processing system after
printout
'Balance': Balance before printout
'data processing
system/balance':
Balance before printout
and output data to the data
processing system after
printout
Block 'Print Total'
Timeout
Printing option
0.0
OFF
0.0
see above
Block 'Analog Source'
Source
Gross This block selects what quantity is issued at the
analog output and how it is scaled.
Some quantities and reference values are:
Source
Dimension for Min/Max
Gross: The scale's dimension
Net: The scale's dimension
dW/dt: The scale's dimension / h
Fieldbus: none; the IEEE value of
the PLS-AIn is issued
Controller magnitude: Not available in Opus;
output is set to 0
Setpoint: The scale's dimension
Actual value %: Percent of setpoint
Actual value of dim: The scale's dimension
Residual value %: Percent of setpoint
Residual value of dim: The scale's dimension
Nex t setpoint The scale's dimension
MIN reference value 0
MAX reference value 0
Block 'PLS-AOut'
Reference value 20 = MAX reference
value
Scaling parallel output of the analog output to PLS
analog output 1.
Block 'Analog Output'
Analog output OFF 4 ... 20 mA
BV-H2313 GB 0630 DISOMAT
®
Opus – Operating Manual
- 118 - © Schenck Process GmbH, Darmstadt
