Setting Mode Setting Using Calibration Password
Enter acquired value and acknowledge with [ENTER] key.
Resume from next spectrum point.
Exit function with [OK] key.
5.4.5.9 Checking Calibration
Check Using Weight
Scale calibration is normally followed by a check using staggered weights. For legal-
for-trade scales, definite Board of Trade regulations have to be observed.
With non-legal-for-trade scales, we suggest to use weights of 25%, 50% and 75% of
full scale value. If unlinearity is detected, you can correct characteristic using the
'Linearization' function (see Menu Item '4452:Linearization').
Check Using Material
With theoretically calibrated scales, a check using calibration weights is often difficult
to perform. In this case, a check using material is recommended.
Weigh a good on your calibrated scale. Its weight should amount to at least 50% of
maximum range. Check this weight on an accurate reference scale. If need be, you
can correct the calibration factor until the two weight indications coincide. If values
differ by multiple percent, an error has occurred.
5.4.6 Fct. 443:Configure Legal-For-Trade Memory
Alternatively to the legal-for-trade printout on a connected (redundant) printer,
DISOMAT offers the possibility to store the legal-for-trade weigh data in an optional
memory (Legal-For-Trade Memory VMM 20400) or in a connected PC. (For
DISOSAVE program, see also Spec Sheet BV-D2045).
If parameter 'L-f-T Memory' is set to 'Low', legal-for-trade results must be printed on
paper.
Operating Sequence
Use DIRECTION KEYS to go to menu item
443:SCALE
Configure l.f.t. memory
and acknowledge with [ENTER] key.
Change parameter and acknowledge with [ENTER] to go to next parameter. After last
parameter program returns to the first, for you to change.
5.4.6.1 Parameter 'Legal-for-Trade Memory'
Display: L.f.T. store Off
Selection: Off, External, Internal
(Default = Off)
Function: Determines weigh data destination
Off = Legal-for-trade memory not used
External = Data are sent to DISOSAVE PC program using
EDP protocol 3964R. User data are transferred in coded
form.
Internal = Data are stored in (optional) DISOMAT legal-for-
trade memory.
DISOMAT
®
Opus – Operating Manual 0630 BV-H2313 GB
© Schenck Process GmbH, Darmstadt - 89 -
