Setting Mode Setting Using Configuration Password
Keyboard:
431:National language support
Keyboard
US-English
Select keyboards with German, US-English, French, Czech, Polish ,Hungarian ,
Russian and Spanish labellings.
Decimal Sign (for representation of numbers):
431:National language support
Decimal point
Comma (,)
Select between Comma (,) and Dot (.).
Operate [OK] key to acquire inputs.
You can additionally activate automatic shift from summer to winter time.
431:National language support
Shift summer/winter time YES
5.3.2.2 Fct. 432:Interfaces
This menu item lets you configure the serial interfaces.
NOTE: All you have to do is configure a physical interface used.
If an EDP system is connected, set interface handshake to 'Off'.
For settings of connected devices, please see relevant device information.
Operating Sequence
Start function and select interface whose parameters are to be set (all settings can be
selected in scroll fields):
432:Interfaces
Interface: S1
There are the following possibilities:
S1, S2, S3
Repeated operation of [ENTER] key lets you select interface transmission
parameter settings.
Enter and acknowledge with [ENTER] key.
Baud rate: (data rate)
432:Interfaces
Baud rate: 9600_
There are the following possibilities:
9600 4800 2400 1200 600 300 19200 38400
Handshake:
432:Interfaces
Handshake: Off
Select between 'Off' and 'On'.
DISOMAT
®
Opus – Operating Manual 0630 BV-H2313 GB
© Schenck Process GmbH, Darmstadt - 63 -
