Normal Mode Functionality in Menu Tree

4.2

l linkages using the F-Feed or D-Feed function

locks. With all other scales, no input is required.

.1 Fct. 1:Enter setpoint

When Is An Input Required?

This function is reserved for automatic filling processes and concerns filling and

discharge scale as well as individua

ATTENTION:

Ensure that setpoint changes do not change actual fill value such that

overfill occurs.

What Can Be Entered?

With automatic filling operations, you can use function to enter material type and

setpoint of the amount to be filled.

Admissible values for material number: [1 ... 2]

Admissible values for setpoint: [0 ... 99999.999 in display unit]

Operating Sequence

Input field displays the material selected last, e.g.

1:Enter Setpoint

Material Number 1

Change data in case of material change.

Enter new material setpoint, if any:

1:Enter Setpoint

Setpoint: 500.00

4.2.2 Fct. 2:String input

In addition to weight, a string is an additional information (on print form), e.g. customer

name, material number, vehicle number.

Up to 5 different strings can be used. Designed for detailed identification of a weighing

operation, their meaning has to be predefined.

Enter relevant contents upon weighing. Some inputs remain constant for a longer

time, others require to be redefined or adapted upon every weighing (before printout).

For a string to appear on printout, the following prerequisites must be given:

• String must be defined (length, prompt) (see '464:String Name' function).

• String must be considered in form format (see '462:Form Formats' function).

• String must include text contents (see '2:Enter String' function).

The first two items belong to 'Setting Mode'; the last item is performed in 'Normal

Mode' and described here below.

BV-H2313 GB 0630 DISOMAT

Opus – Operating Manual
