Schenck process Disomat Opus User Manual

Function Variants Weighbridge ZEUS
6.6.13 Parameters
Table of parameters for the 'Road Weigh Bridge Function Variant'
Parameter Name Default Required
Setting
Recommended
Setting
Comments
Block 'Output 3'
FastComp.High
FastComp.Low
HIGH > LOW
LOW > HIGH
Min. contact
Max. contact
Block 'Output 4'
FastComp.High
FastComp.Low
LOW > HIGH
HIGH > LOW
Max. contact
Min. contact
Block 'Weighing'
Timeout 20.0
0 sec: Print-out without no-motion
state monitoring
1-999 sec: Waiting-time to no-motion
state.
Printing option Balance
'OFF': No data output to the data
processing system and no
balancing
'to data
processing
system':
Data output to the data
processing system after
printout
Balance before printout 'Balance':
'data processing
system/balance':
Balance before printout
and output data to the data
processing system after
printout
Block 'Print Total'
Timeout
Printing option
0.0
OFF
0.0 see above
Block 'Analog Source'
Source
Gross This block selects what quantity is issued at the
analog output and how it is scaled.
Some quantities and reference values are:
Source
Dimension for Min/Max
Gross: The scale's dimension
Net: The scale's dimension
dW/dt: The scale's dimension / h
Fieldbus: none; the IEEE value of the
PLS-AIn is issued
Controller
magnitude:
Not available in Opus;
output is set to 0
Setpoint: The scale's dimension
Actual value %: Percent of setpoint
Actual value of dim: The scale's dimension
Residual value %: Percent of setpoint
Residual value of
dim:
The scale's dimension
Next setpoint The scale's dimension
MIN reference value 0
MAX reference value 0
Block 'PLS-AOut'
Reference value 20 = MAX
reference value
Scaling the parallel output of the analog output to
PLS analog output 1.
Block 'Analog Output'
Analog output OFF 4 - 20 mA
DISOMAT
®
Opus – Operating Manual 0630 BV-H2313 GB
© Schenck Process GmbH, Darmstadt - 129 -
