Function Variants Weighbridge ZEUS
6.6.11 ZEUS Print Pattern Codes
'EW' = Weight from first weighing
'EU' = Time of first weighing
'ED' = Date of first weighing
'ZW' = Weight from second weighing
'ZU' = Time of second weighing
'ZD' = Date of second weighing
'KF' = Vehicle number
'SN' = Material number
'SO' = Material name
'WN' = First weighing memory number
'WE' = Weight difference, weighing result (first weighing minus second weighing)
6.6.12 Signal Control Using DISOMAT Opus-ZEUS
The standard DISOMAT Opus-ZEUS is capable of controlling a signal system
consisting of entrance and exit signal, each with one red and one green light. Signal
control is as follows:
• When vehicle drives onto scale, entrance and exit are closed to traffic (RED
signal).
• If weighing is complete, exit signal turns GREEN.
• If scale is totally relieved, entrance signal also turns GREEN, and scale is
ready for next weighing operation.
A single exit signal, i.e. signal system with red light only, is controlled in the same
fashion.
If a vehicle drives on scale inadvertently, exit can be released with key combination
+
and no weighing takes place.
Connecting signal system to ZEUS:
Contact: concerns: Function:
XDO Contact 2 Output 1 Exit signal, RED light
XDO Contact 3 Output 2 Exit signal, GREEN light
XDO Contact 4 Output 3 Entrance signal, RED light
XDO Contact 5 Output 4 Entrance signal, GREEN light
XDO Contact 1 Outputs 1-4 Common root
Operating sequence can be set to "Weighing Complete" (GREEN exit signal) via EDP
command.
DISOMAT Opus outputs can control 230V lights directly. Cables of 1.5 mm
2
cross-
section per core can be connected directly.
The traffic signal thresholds are preset with 1% of full scale "(scale loaded)" and
0.01% "(scale empty)".
BV-H2313 GB 0630 DISOMAT
®
Opus – Operating Manual
- 128 - © Schenck Process GmbH, Darmstadt
