Setting Mode Setting Using Configuration Password
c) DeviceNet
Parameter Input
Own address _8
Baud rate 250kB
300kB
Data format No text/4 ID
Text/2 ID
Swapping LITTLE Endian
BIG Endian
BYTE Swap
WORD Swap
Timeout _10.0s
d) Modbus/TCP
Parameter Input
Timeout _10,0s
After parameter setting, acknowledge with [OK] key. For synchronization, DISOMAT
performs a restart if Profibus has been selected.
For details (procedures/parameters), see 'Data Communication Manual'
(BVH2316).
5.3.2.8 Fct. 434:Event Classes
The DISOMAT display upper line (message area) outputs hints on events during
operation in turn with scale information.
Example
: A0209:Powerfail
To enable an event occurring during operation to be judged by its importance, it is
assigned to an event class. The following classes have been defined: Message,
Warning, Alarm and Fault.
If an event message is displayed, you will know its class by the first letter:
M = Message, W = Warning, A = Alarm, S = Fault.
For complete list of event messages and information on their construction,
see Chapter 7.
Using this function you can edit the event class for some events that may occur:
Event Message Editable Default Event Class
W01XX:Timeout Warning
A02XX:Power Failure Alarm
A03XX:Restart Alarm
M06XX:No No-Motion Message
M07XX:Out of Zeroing Range Message
M08XX:Tare Value Too Small Message
A20XX:Printer Fault Alarm
W21XX:Tare > Gross Warning
W22XX:External Legal-For-Trade Memory Warning
A23XX:Legal-For-Trade Memory FULL Alarm
DISOMAT
®
Opus – Operating Manual 0630 BV-H2313 GB
© Schenck Process GmbH, Darmstadt - 69 -
