Function Variants Crane Scale
6.4.3 Inputs and Outputs
Inputs:
Phys. Signal Function:
In 1: PLS-DIn1 Set Tare / Clear Tare
In 2: n/a Set to zero / Test (short)
Quit Event message (long)
In 3: PLS-DIn3 Print total and clear balance
In 4: PLS-DIn4 Weigh and print
n/a PLS-DIn2 Quit event message
n/a PLS-DIn5 Set to zero / Test
Outputs:
Phys. Signal Function:
Out 1: PLS-DOut1 Slagging rope
Out 2: PLS-DOut2 Overload
Out 3: PLS-DOut3 Switching the elevated load to higher performance
Out 4: PLS-DOut4 Ready to operate (no fault)
AnalogOut n/a Depending on choice
The PLS-DIn or PLS-DOut signals are used to control the scale by computer or
fieldbus. They function at the same time as the physical inputs or outputs.
Exceptions: PLS-DIn2 Quit event message
PLS-DIn5 Set to zero / Test
BV-H2313 GB 0630 DISOMAT
®
Opus – Operating Manual
- 110 - © Schenck Process GmbH, Darmstadt
