Setting Mode Safety Through Password Protection
5 Setting Mode
'Setting Mode' operating mode is protected by password. Here you exclusively use
menu tree functions designed for
• PARAMETRIZATION - Perform parameter settings in DISOMAT which are
but seldom required. Before calling functions (see Item 5.2), enter Parameter
password.
• CONFIGURATION - Perform control system settings. Before calling functions
(see Item 5.3), enter Configuraiton password. This privilege includes the
permission for parametrization.
• CALIBRATION - Set and calibrate weighing system. Before calling functions
(see Item 5.4), enter Calibration password.
As convenient servicing tool, SCHENCK PROCESS have developed the
DISOPLAN PC program.
Calling up setting mode
Call up menu tree, go to function
4:MENU TREE
SETTINGS
and operate [DOWN arrow] key.
System prompts for password input.
41:SETTINGS
Enter Password
(see Item 5.1).
After password input, the relevant menu items are faded in into menu tree. You will
note that menu items are not strictly divided by the above three privilege grades. For
practical reasons, some menu items are available under multiple passwords.
5.1 Safety Through Password Protection
For safety reasons, access to functions is protected by a graded password system
designed to protect the DISOMAT settings.
In addition to the generally accessible area, there are further areas protected by
password:
• Parameter password for daily use
• Configuration password for commissioning
• Calibration password for weighing functions commissioning
• Restart password for restart ('Reset all' - For reloading of RAM, see Item
5.5).
• Service password for SCHENCK internal use. Opens further menu items
reserved for authorized service engineers.
DISOMAT
®
Opus – Operating Manual 0630 BV-H2313 GB
© Schenck Process GmbH, Darmstadt - 41 -
