701 Motor Protection Relay Date Code 20010719

Modbus

RTU Communications Protocol

Modbus Register Map

C.24

Table C.18 Modbus Register Map (Continued)

Address

(hex)

Field

Sample

Low

High

Step

Type

THERMAL METERING

0190

Temperature

Preference

67 = C; 70 = F 67 70

0191

Hottest

Winding RTD

See Note 1

See

Note 3

See

Note 3

0192

Hottest

Bearing RTD

See Note 1

See

Note 3

See

Note 3

0193 Ambient RTD See Note 1

See

Note 3

See

Note 3

0194

Hottest

Other RTD

See Note 1

See

Note 3

See

Note 3

0195

RTD #1

Temperature

See Note 2

See

Note 3

See

Note 3

0196

RTD #2

Temperature

See Note 2

See

Note 3

See

Note 3

0197

RTD #3

Temperature

See Note 2

See

Note 3

See

Note 3

0198

RTD #4

Temperature

See Note 2

See

Note 3

See

Note 3

0199

RTD #5

Temperature

See Note 2

See

Note 3

See

Note 3

019A

RTD #6

Temperature

See Note 2

See

Note 3

See

Note 3

019B

RTD #7

Temperature

See Note 2

See

Note 3

See

Note 3

019C

RTD #8

Temperature

See Note 2

See

Note 3

See

Note 3

019D

RTD #9

Temperature

See Note 2

See

Note 3

See

Note 3

019E

RTD #10

Temperature

See Note 2

See

Note 3

See

Note 3

019F

RTD #11

Temperature

See Note 2

See

Note 3

See

Note 3

01A0

RTD #12

Temperature

See Note 2

See

Note 3

See

Note 3
