Date Code 20010719 701 Motor Protection Relay

Modbus

RTU Communications Protocol

Modbus Register Map

C.25

Table C.18 Modbus Register Map (Continued)

Address

(hex)

Field

Sample

Low

High

Step

Type

01A1 % of FLA 0 65535 1 • 0.1

01A2

% Thermal

Capacity

0 65535 1 • 0.1

01A3

RTD

% Thermal

Capacity

0 if no

RTDs available

0 65535 1

01A4 Time to Trip ss 0 9999 1, 1

01A5

Minutes

Since Last Start

0 65535 1

01A6

Starts

This Hour

0 99 1

01A7 Reserved

01A8 Reserved

01A9 Reserved

01AA Reserved

01AB Reserved

01AC Reserved

01AD Reserved

01AE Reserved

01AF Reserved

ENERGY METERING

01B0 MWhr

0 if no

voltage option

0 65535 1

01B1 MVARhr In

0 if no

voltage option

0 65535 1

01B2 MVARhr Out

0 if no

voltage option

0 65535 1

01B3 MVAhr

0 if no

voltage option

0 65535 1

01B4 Last Reset Date mm, dd 1, 1 12, 31 1, 1

01B5 yyyy 0 65535 1

01B6

Last

Reset Time

hh, mm 0, 0 23, 59 1, 1

(Continued)
