701 Motor Protection Relay Date Code 20010719
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.26
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
01B7 ssss 0 5999 1 • 0.01
01B8 Reserved
01B9 Reserved
01BA Reserved
01BB Reserved
01BC Reserved
01BD Reserved
01BE Reserved
01BF Reserved
DEMAND METERING
01C0 Ia Demand 0 65535 1
01C1 Ib Demand 0 65535 1
01C2 Ic Demand 0 65535 1
01C3 In Demand 0 65535 1
01C4 Ig Demand 0 65535 1
01C5 3I2 Demand 0 65535 1
01C6
kW3P
Demand
0 if no
voltage option
0 65535 1
01C7
kVAR3P
Demand In
0 if no
voltage option
0 65535 1
01C8
kVAR3P
Demand Out
0 if no
voltage option
0 65535 1
01C9
kVA3P
Demand
0 if no
voltage option
0 65535 1
01CA Last Reset Date mm, dd 1, 1 12, 31 1, 1
01CB yyyy 0 65535 1
01CC
Last
Reset Time
hh, mm 0, 0 23, 59 1, 1
01CD ssss 0 5999 1 • 0.01
01CE Reserved
01CF Reserved
(Continued)
