Schweitzer Engineering Laboratories SEL-701 - Page 317

Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.27
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
PEAK DEMAND METERING
01D0
Ia Peak
Demand
0 65535 1
01D1
Ib Peak
Demand
0 65535 1
01D2
Ic Peak
Demand
0 65535 1
01D3
In Peak
Demand
0 65535 1
01D4
Ig Peak
Demand
0 65535 1
01D5
3I2 Peak
Demand
0 65535 1
01D6
kW3P
Peak Demand
0 if no
voltage option
0 65535 1
01D7
kVAR3P Peak
Demand In
0 if no
voltage option
0 65535 1
01D8
kVAR3P Peak
Demand Out
0 if no
voltage option
0 65535 1
01D9
kVA3P
Peak Demand
0 if no
voltage option
0 65535 1
01DA Last Reset Date mm, dd 1, 1 12, 31 1, 1
01DB yyyy 0 65535 1
01DC
Last
Reset Time
hh, mm 0, 0 23, 59 1, 1
01DD ssss 0 5999 1 • 0.01
01DE Reserved
01DF Reserved
CURRENT MAX/MIN METERING
01E0 Ia Max Current (FFFFh if reset) 0 65535 1
01E1
Ia Max
Current Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
01E2
yyyy
(FFFFh if reset)
0 65535 1
(Continued)
