701 Motor Protection Relay Date Code 20010719
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.28
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
01E3
Ia Max
Current Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
01E4
ssss
(FFFFh if reset)
0 5999 1 • 0.01
01E5 Ia Min Current (FFFFh if reset) 0 65535 1
01E6
Ia Min
Current Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
01E7
yyyy
(FFFFh if reset)
0 65535 1
01E8
Ia Min
Current Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
01E9
ssss
(FFFFh if reset)
0 5999 1 • 0.01
01EA Ib Max Current (FFFFh if reset) 0 65535 1
01EB
Ib Max
Current Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
01EC
yyyy
(FFFFh if reset)
0 65535 1
01ED
Ib Max
Current Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
01EE
ssss
(FFFFh if reset)
0 5999 1 • 0.01
01EF Ib Min Current (FFFFh if reset) 0 65535 1
01F0
Ib Min
Current Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
01F1
yyyy
(FFFFh if reset)
0 65535 1
01F2
Ib Min
Current Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
01F3
ssss
(FFFFh if reset)
0 5999 1 • 0.01
01F4 Ic Max Current (FFFFh if reset) 0 65535 1
01F5
Ic Max
Current Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
01F6
yyyy
(FFFFh if reset)
0 65535 1
(Continued)
