701 Motor Protection Relay Date Code 20010719
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.30
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
020A
yyyy
(FFFFh if reset)
0 65535 1
020B
Ig Max
Current Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
020C
ssss
(FFFFh if reset)
0 5999 1 • 0.01
020D Ig Min Current (FFFFh if reset) 0 65535 1
020E
Ig Min
Current Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
020F
yyyy
(FFFFh if reset)
0 65535 1
0210
Ig Min
Current Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0211
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0212 Last Reset Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0213
yyyy
(FFFFh if reset)
0 65535 1
0214
Last
Reset Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0215
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0216–
021F
Reserved
RTD MAX/MIN METERING
0220
RTD # 1 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0221
RTD # 1 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0222
yyyy
(FFFFh if reset)
0 65535 1
0223
RTD # 1 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
(Continued)
