Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.31
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
0224
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0225
RTD # 1 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0226
RTD # 1 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0227
yyyy
(FFFFh if reset)
0 65535 1
0228
RTD # 1 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0229
ssss
(FFFFh if reset)
0 5999 1 • 0.01
022A
RTD # 2 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
022B
RTD # 2 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
022C
yyyy
(FFFFh if reset)
0 65535 1
022D
RTD # 2 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
022E
ssss
(FFFFh if reset)
0 5999 1 • 0.01
022F
RTD # 2 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0230
RTD # 2 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0231
yyyy
(FFFFh if reset)
0 65535 1
0232
RTD # 2 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
(Continued)
