Modbus Register Map
C.32
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
0233
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0234
RTD # 3 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0235
RTD # 3 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0236
yyyy
(FFFFh if reset)
0 65535 1
0237
RTD # 3 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0238
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0239
RTD # 3 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
023A
RTD # 3 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
023B
yyyy
(FFFFh if reset)
00 65535 1
023C
RTD # 3 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
023D
ssss
(FFFFh if reset)
0 5999 1 • 0.01
023E
RTD # 4 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
023F
RTD # 4 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0240
yyyy
(FFFFh if reset)
0 65535 1
0241
RTD # 4 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
