Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.33
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
0242
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0243
RTD # 4 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0244
RTD # 4 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0245
yyyy
(FFFFh if reset)
0 65535 1
0246
RTD # 4 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0247
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0248
RTD # 5 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0249
RTD # 5 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
024A
yyyy
(FFFFh if reset)
0 65535 1
024B
RTD # 5 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
024C
ssss
(FFFFh if reset)
0 5999 1 • 0.01
024D
RTD # 5 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
024E
RTD # 5 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
024F
yyyy
(FFFFh if reset)
0 65535 1
0250
RTD # 5 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
(Continued)
