Schweitzer Engineering Laboratories SEL-701 - Page 324

701 Motor Protection Relay Date Code 20010719
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.34
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
0251
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0252
RTD # 6 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0253
RTD # 6 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0254
yyyy
(FFFFh if reset)
0 65535 1
0255
RTD # 6 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0256
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0257
RTD # 6 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0258
RTD # 6 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0259
yyyy
(FFFFh if reset)
0 65535 1
025A
RTD # 6 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
025B
ssss
(FFFFh if reset)
0 5999 1 • 0.01
025C
RTD # 7 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
025D
RTD # 7 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
025E
yyyy
(FFFFh if reset)
0 65535 1
025F
RTD # 7 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
(Continued)
