Schweitzer Engineering Laboratories SEL-701 - Page 325

Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.35
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
0260
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0261
RTD # 7 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0262
RTD # 7 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0263
yyyy
(FFFFh if reset)
0 65535 1
0264
RTD # 7 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0265
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0266
RTD # 8 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0267
RTD # 8 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0268
yyyy
(FFFFh if reset)
0 65535 1
0269
RTD # 8 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
026A
ssss
(FFFFh if reset)
0 5999 1 • 0.01
026B
RTD # 8 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
026C
RTD # 8 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
026D
yyyy
(FFFFh if reset)
0 65535 1
026E
RTD # 8 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
(Continued)
