Schweitzer Engineering Laboratories SEL-701 - Page 326

701 Motor Protection Relay Date Code 20010719
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.36
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
026F
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0270
RTD # 9 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0271
RTD # 9 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0272
yyyy
(FFFFh if reset)
0 65535 1
0273
RTD # 9 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0274
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0275
RTD # 9 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0276
RTD # 9 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0277
yyyy
(FFFFh if reset)
0 65535 1
0278
RTD # 9 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0279
ssss
(FFFFh if reset)
0 5999 1 • 0.01
027A
RTD # 10 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
027B
RTD # 10 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
027C
yyyy
(FFFFh if reset)
0 65535 1
027D
RTD # 10 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
(Continued)
