Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.37
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
027E
ssss
(FFFFh if reset)
0 5999 1 • 0.01
027F
RTD # 10 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0280
RTD # 10 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0281
yyyy
(FFFFh if reset)
0 65535 1
0282
RTD # 10 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0283
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0284
RTD # 11 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0285
RTD # 11 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0286
yyyy
(FFFFh if reset)
0 65535 1
0287
RTD # 11 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0288
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0289
RTD # 11 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
028A
RTD # 11 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
028B
yyyy
(FFFFh if reset)
0 65535 1
028C
RTD # 11 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
(Continued)
