Schweitzer Engineering Laboratories SEL-701 - Page 328

701 Motor Protection Relay Date Code 20010719
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.38
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
028D
ssss
(FFFFh if reset)
0 5999 1 • 0.01
028E
RTD # 12 Max
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
028F
RTD # 12 Max
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0290
yyyy
(FFFFh if reset)
0 65535 1
0291
RTD # 12 Max
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0292
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0293
RTD # 12 Min
Temperature
FFFFh if reset
or no RTD
See
Note 3
See
Note 3
1
0294
RTD # 12 Min
Temperature
Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0295
yyyy
(FFFFh if reset)
0 65535 1
0296
RTD # 12 Min
Temperature
Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
0297
ssss
(FFFFh if reset)
0 5999 1 • 0.01
0298 Last Reset Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
0299
yyyy
(FFFFh if reset)
0 65535 1
029A
Last
Reset Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
029B
ssss
(FFFFh if reset)
0 5999 1 • 0.01
029C Reserved
029D Reserved
(Continued)
