701 Motor Protection Relay Date Code 20010719
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.40
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
02AF
Vbc
Min Voltage
(FFFFh if
reset or no
voltage option)
0 65535 1
02B0
Vbc Min
Voltage Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
02B1
yyyy
(FFFFh if reset)
0 65535 1
02B2
Vbc Min
Voltage Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
02B3
ssss
(FFFFh if reset)
0 5999 1 • 0.01
02B4
Vca
Max Voltage
(FFFFh if
reset or no
voltage option)
0 65535 1
02B5
Vca Max
Voltage Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
02B6
yyyy
(FFFFh if reset)
0 65535 1
02B7
Vca Max
Voltage Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
02B8
ssss
(FFFFh if reset)
0 5999 1 • 0.01
02B9
Vca
Min Voltage
(FFFFh if
reset or no
voltage option)
0 65535 1
02BA
Vca Min
Voltage Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
02BB
yyyy
(FFFFh if reset)
0 65535 1
02BC
Vca Min
Voltage Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
02BD
ssss
(FFFFh if reset)
0 5999 1 • 0.01
02BE
Vg
Max Voltage
(FFFFh if
reset or no
voltage option)
0 65535 1
(Continued)
