Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.41
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
02BF
Vg Max
Voltage Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
02C0
yyyy
(FFFFh if reset)
0 65535 1
02C1
Vg Max
Voltage Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
02C2
ssss
(FFFFh if reset)
0 5999 1 • 0.01
02C3
Vg
Min Voltage
(FFFFh if
reset or no
voltage option)
0 65535 1
02C4
Vg Min
Voltage Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
02C5
yyyy
(FFFFh if reset)
0 65535 1
02C6
Vg Min
Voltage Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
02C7
ssss
(FFFFh if reset)
0 5999 1 • 0.01
02C8
Max
kW3P Power
(FFFFh if
reset or no
voltage option)
–32768 32767 1
02C9
Max kW3P
Power Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
02CA
yyyy
(FFFFh if reset)
0 65535 1
02CB
Max kW3P
Power Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
02CC
ssss
(FFFFh if reset)
0 5999 1 • 0.01
02CD
Min
kW3P Power
(FFFFh if
reset or no
voltage option)
–32768 32767 1
02CE
Min kW3P
Power Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
02CF
yyyy
(FFFFh if reset)
0 65535 1
(Continued)
