Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.43
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
02E1
Min
kVA3P Power
(FFFFh if
reset or no
voltage option)
0 65535 1
02E2
Min kVA3P
Power Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
02E3
yyyy
(FFFFh if reset)
0 65535 1
02E4
Min kVA3P
Power Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
02E5
ssss
(FFFFh if reset)
0 5999 1 • 0.01
02E6 Last Reset Date
mm, dd
(FFFFh if reset)
1, 1 12, 31 1, 1
02E7
yyyy
(FFFFh if reset)
0 65535 1
02E8
Last
Reset Time
hh, mm
(FFFFh if reset)
0, 0 23, 59 1, 1
02E9
ssss
(FFFFh if reset)
0 5999 1 • 0.01
02EA Reserved
02EB Reserved
02EC Reserved
02ED Reserved
02EE Reserved
02EF Reserved
MOTOR STATISTICS
02F0 Elapsed Time ddd 0 65535 1
02F1 hh, mm 0, 0 23, 59 1, 1
02F2 Running Time ddd 0 65535 1
02F3 hh, mm 0, 0 23, 59 1, 1
02F4 Stopped Time ddd 0 65535 1
02F5 hh, mm 0, 1 23, 60 1, 2
02F6
% Time
Running
0 1000 1 • 0.1
(Continued)
