701 Motor Protection Relay Date Code 20010719
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.44
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
02F7 MegaWhr 0 65535 1
02F8 # of Starts 0 65535 1
02F9
Avg
Starting Time
seconds 0 65535 1 • 0.01
02FA
Avg Starting
Current
0 65535 1
02FB
Avg Minimum
Starting
Voltage
0 if no
voltage option
0 65535 1
02FC
Avg Starting
% Therm Cap
0 65535 1 • 0.1
02FD
Avg Running
% Therm Cap
0 65535 1 • 0.1
02FE
Avg RTD
% Therm Cap
0 65535 1
02FF
Avg Running
Current
0 65535 1
0300
Avg
Running kW
0 if no
voltage option
0 65535 1
0301
Avg Running
kVAR In
0 if no
voltage option
0 65535 1
0302
Avg Running
kVAR Out
0 if no
voltage option
0 65535 1
0303
Avg
Running kVA
0 if no
voltage option
0 65535 1
0304
Avg Hottest
Winding RTD
Temp
See Note 1
See
Note 3
See
Note 3
1
0305
Avg Hottest
Bearing RTD
Temp
See Note 1
See
Note 3
See
Note 3
1
0306
Avg Ambient
RTD Temp
See Note 1
See
Note 3
See
Note 3
1
0307
Avg Hottest
Other RTD
Temp
See Note 1
See
Note 3
See
Note 3
1
(Continued)
