Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.45
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
0308
Peak
Starting Time
seconds 0 65535 1 • 0.01
0309
Peak Starting
Current
0 65535 1
030A
Peak Minimum
Starting
Voltage
0 if no
voltage option
0 65535 1
030B
Peak Starting
% Therm Cap
0 65535 1 • 0.1
030C
Peak Running
% Therm Cap
0 65535 1 • 0.1
030D
Peak RTD
% Therm Cap
0 65535 1
030E
Peak Running
Current
0 65535 1
030F
Peak
Running kW
0 if no
voltage option
0 65535 1
0310
Peak Running
kVAR In
0 if no
voltage option
0 65535 1
0311
Peak Running
kVAR Out
0 if no
voltage option
0 65535 1
0312
Peak Running
kVA
0 if no
voltage option
0 65535 1
0313
Peak Hottest
Winding RTD
Temp
See Note 1
See
Note 3
See
Note 3
1
0314
Peak Hottest
Bearing RTD
Temp
See Note 1
See
Note 3
See
Note 3
1
0315
Peak Ambient
RTD Temp
See Note 1
See
Note 3
See
Note 3
1
0316
Peak Hottest
Other RTD
Temp
See Note 1
See
Note 3
See
Note 3
1
0317
Stopped
Cooling Time
Minutes 0 65535 1 • 0.1
(Continued)
