Schweitzer Engineering Laboratories SEL-701 - Page 336

701 Motor Protection Relay Date Code 20010719
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.46
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
0318
Starting
Thermal
Capacity
0 65535 1 • 0.1
0319
Thermal
Alarm Count
0 65535 1
031A
Locked Rotor
Alarm Count
0 65535 1
031B
Load Loss
Alarm Count
0 65535 1
031C
Unbalance
Current Alarm
Count
0 65535 1
031D
Under Power
Alarm Count
0 65535 1
031E
Power Factor
Alarm Count
0 65535 1
031F
Reactive Power
Alarm Count
0 65535 1
0320
RTD
Alarm Count
0 65535 1
0321
Total
Alarm Count
0 65535 1
0322
Thermal
Trip Count
0 65535 1
0323
Locked Rotor
Trip Count
0 65535 1
0324
Load Loss
Trip Count
0 65535 1
0325
Load Jam
Trip Count
0 65535 1
0326
Unbalance
Current Trip
Count
0 65535 1
0327
Phase Fault
Trip Count
0 65535 1
0328
Ground Fault
Trip Count
0 65535 1
(Continued)
