Date Code 20010719 701 Motor Protection Relay

Modbus

RTU Communications Protocol

Modbus Register Map

C.47

Table C.18 Modbus Register Map (Continued)

Address

(hex)

Field

Sample

Low

High

Step

Type

0329

Speed Switch

Trip Count

0 65535 1

032A

Undervoltage

Trip Count

0 65535 1

032B

Overvoltage

Trip Count

0 65535 1

032C

Under Power

Trip Count

0 65535 1

032D

Power Factor

Trip Count

0 65535 1

032E

Reactive Power

Trip Count

0 65535 1

032F

Phase Reversal

Trip Count

0 65535 1

0330

Under-

frequency Trip

Count

0 65535 1

0331

Over-frequency

Trip Count

0 65535 1

0332 RTD Trip 0 65535 1

0333 Total Trip 0 65535 1

0334 Reset Date mm, dd 1, 1 12, 31 1, 1

0335 yyyy 0 65535 1

0336 Reset Time hh, mm 0, 0 23, 59 1, 1

0337 ssss 0 5999 1 • 0.01

0338 Reserved

0339 Reserved

033A Reserved

033B Reserved

033C Reserved

033D Reserved

033E Reserved

033F Reserved

(Continued)
