701 Motor Protection Relay Date Code 20010719
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.48
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
START REPORT SUMMARIES
0340
Latest
Accel Time
seconds 0 65535 1 • 0.01
0341
Latest Starting
% Therm Cap
0 65535 1 • 0.1
0342
Latest Max
Start Current
0 65535 1
0343
Latest Min
Start Voltage
0 if no
voltage option
0 65535 1
0344
Latest
Start Date
mm, dd 1, 1 12, 31 1, 1
0345 yyyy 0 65535 1
0346
Latest
Start Time
hh, mm 0, 0 23, 59 1, 1
0347 ssss 0 5999 1 • 0.01
0348
2nd Latest
Accel Time
seconds 0 65535 1 • 0.01
0349
2nd Latest
Starting %
Therm Cap
0 65535 1 • 0.1
034A
2nd Latest Max
Start Current
0 65535 1
034B
2nd Latest Min
Start Voltage
0 if no
voltage option
0 65535 1
034C
2nd Latest
Start Date
mm, dd 1, 1 12, 31 1, 1
034D yyyy 0 65535 1
034E
2nd Latest
Start Time
hh, mm 0, 0 23, 59 1, 1
034F ssss 0 5999 1 • 0.01
0350
3rd Latest
Accel Time
seconds 0 65535 1 • 0.01
0351
3rd Latest
Starting
% Therm Cap
0 65535 1 • 0.1
(Continued)
