Schweitzer Engineering Laboratories SEL-701 - Page 339

Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.49
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
0352
3rd Latest Max
Start Current
0 65535 1
0353
3rd Latest Min
Start Voltage
0 if no
voltage option
0 65535 1
0354
3rd Latest
Start Date
mm, dd 1, 1 12, 31 1, 1
0355 yyyy 0 65535 1
0356
3rd Latest
Start Time
hh, mm 0, 0 23, 59 1, 1
0357 ssss 0 5999 1 • 0.01
0358
4th Latest
Accel Time
seconds 0 65535 1 • 0.01
0359
4th Latest
Starting
% Therm Cap
0 65535 1 • 0.1
035A
4th Latest Max
Start Current
0 65535 1
035B
4th Latest Min
Start Voltage
0 if no
voltage option
0 65535 1
035C
4th Latest
Start Date
mm, dd 1, 1 12, 31 1, 1
035D yyyy 0 65535 1
035E
4th Latest
Start Time
hh, mm 0, 0 23, 59 1, 1
035F ssss 0 5999 1 • 0.01
0360
5th Latest
Accel Time
seconds 0 65535 1 • 0.01
0361
5th Latest
Starting
% Therm Cap
0 65535 1 • 0.1
0362
5th Latest Max
Start Current
0 65535 1
0363
5th Latest Min
Start Voltage
0 if no
voltage option
0 65535 1
0364
5th Latest
Start Date
mm, dd 1, 1 12, 31 1, 1
(Continued)
