Schweitzer Engineering Laboratories SEL-701 - Page 342

701 Motor Protection Relay Date Code 20010719
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.52
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
03A4 2/4 Cycle –32768 32767 1
03A5 3/4 Cycle –32768 32767 1
03A6 1 Cycle –32768 32767 1
03A7 1 1/4 Cycle –32768 32767 1
03A8 1 2/4 Cycle –32768 32767 1
03A9 1 3/4 Cycle –32768 32767 1
03AA 2 Cycle –32768 32767 1
03AB 2 1/4 Cycle –32768 32767 1
03AC 2 2/4 Cycle –32768 32767 1
03AD 2 3/4 Cycle –32768 32767 1
03AE 3 Cycle –32768 32767 1
03AF 3 1/4 Cycle –32768 32767 1
03B0 3 2/4 Cycle –32768 32767 1
03B1 3 3/4 Cycle –32768 32767 1
03B2 4 Cycle –32768 32767 1
03B3 4 1/4 Cycle –32768 32767 1
03B4 4 2/4 Cycle –32768 32767 1
03B5 4 3/4 Cycle –32768 32767 1
03B6 5 Cycle –32768 32767 1
03B7 5 1/4 Cycle –32768 32767 1
03B8 5 2/4 Cycle –32768 32767 1
03B9 5 3/4 Cycle –32768 32767 1
03BA 6 Cycle –32768 32767 1
03BB 6 1/4 Cycle –32768 32767 1
03BC 6 2/4 Cycle –32768 32767 1
03BD 6 3/4 Cycle –32768 32767 1
03BE 7 Cycle –32768 32767 1
03BF 7 1/4 Cycle –32768 32767 1
03C0 7 2/4 Cycle –32768 32767 1
03C1 7 3/4 Cycle –32768 32767 1
03C2 8 Cycle –32768 32767 1
(Continued)
