Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.53
Table C.18 Modbus Register Map (Continued)
Address
(hex) Field Sample Low High Step Type
03C3 8 1/4 Cycle –32768 32767 1
03C4 8 2/4 Cycle –32768 32767 1
03C5 8 3/4 Cycle –32768 32767 1
03C6 9 Cycle –32768 32767 1
03C7 9 1/4 Cycle –32768 32767 1
03C8 9 2/4 Cycle –32768 32767 1
03C9 9 3/4 Cycle –32768 32767 1
03CA 10 Cycle –32768 32767 1
03CB 10 1/4 Cycle –32768 32767 1
03CC 10 2/4 Cycle –32768 32767 1
03CD 10 3/4 Cycle –32768 32767 1
03CE 11 Cycle –32768 32767 1
03CF 11 1/4 Cycle –32768 32767 1
03D0 11 2/4 Cycle –32768 32767 1
03D1 11 3/4 Cycle –32768 32767 1
03D2 12 Cycle –32768 32767 1
03D3 12 1/4 Cycle –32768 32767 1
03D4 12 2/4 Cycle –32768 32767 1
03D5 12 3/4 Cycle –32768 32767 1
03D6 13 Cycle –32768 32767 1
03D7 13 1/4 Cycle –32768 32767 1
03D8 13 2/4 Cycle –32768 32767 1
03D9 13 3/4 Cycle –32768 32767 1
03DA 14 Cycle –32768 32767 1
03DB 14 1/4 Cycle –32768 32767 1
03DC 14 2/4 Cycle –32768 32767 1
03DD 14 3/4 Cycle –32768 32767 1
03DE 15 Cycle –32768 32767 1
03DF Reserved
