Date Code 20010719 701 Motor Protection Relay
SEL-2020/2030 & SEL-701PC Compatibility Features
Fast Binary Message Definitions
D.5
Table D.4 A5C1 Fast Meter Configuration Block (Continued)
Data Description
xxxx Digital offset (specific value of xxxx based on
relay model, as shown below)
0030 Base Relay
0038 Relay with RTDs
0058 Relay with voltages
0060 Relay with RTDs, voltages
494100000000 Analog channel name (IA)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
494200000000 Analog channel name (IB)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
494300000000 Analog channel name (IC)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
494E00000000 Analog channel name (IN)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
334932000000 Analog channel name (3I2)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
(Continued)
To Next Page
