Schweitzer Engineering Laboratories SEL-701 - Page 352

701 Motor Protection Relay Date Code 20010719
SEL-2020/2030 & SEL-701PC Compatibility Features
Fast Binary Message Definitions
D.6
Table D.4 A5C1 Fast Meter Configuration Block (Continued)
Data Description
25556E62616C Analog channel name (%Unbal)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
465245510000 Analog channel name (Freq)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
25544845524D Analog channel name (%Therm)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
25464C410000 Analog channel name (%FLA)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
If the Relay Is Equipped With Voltage Inputs
564142000000 Analog channel name (VAB)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
564243000000 Analog channel name (VBC)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
(Continued)
