Date Code 20010719 701 Motor Protection Relay
SEL-2020/2030 & SEL-701PC Compatibility Features
Fast Binary Message Definitions
D.7
Table D.4 A5C1 Fast Meter Configuration Block (Continued)
Data Description
564341000000 Analog channel name (VCA)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
564700000000 Analog channel name (VG)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
335632000000 Analog channel name (3V2)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
6B5700000000 Analog channel name (kW)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
485000000000 Analog channel name (HP)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
6B5641000000 Analog channel name (kVAR)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
(Continued)
