701 Motor Protection Relay Date Code 20010719
SEL-2020/2030 & SEL-701PC Compatibility Features
Fast Binary Message Definitions
D.8
Table D.4 A5C1 Fast Meter Configuration Block (Continued)
Data Description
706600000000 Analog channel name (pf)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
If the Relay Is Equipped With Internal or External RTD Inputs
574447000000
Analog channel name (WDG)
[Hottest Winding RTD Temp.]
00 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
425247000000 Analog channel name (BRG)
[Hottest Bearing RTD Temp.]
00 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
414D42000000 Analog channel name (AMB)
[Ambient RTD Temp.]
00 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
4F5448000000 Analog channel name (OTH)
[Hottest Other RTD Temp.]
00 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
All Versions
00 Reserved
checksum 1-byte checksum of all preceding bytes
