Schweitzer Engineering Laboratories SEL-701 - Page 393

Date Code 20010719 701 Motor Protection Relay
Date ___________
Created by ___________
Factory Defaults
Time to Trip at 1.40 x FLA
Range: 1.0–6000.0 s, NP TTT140 = (Hidden)
Time to Trip at 1.50 x FLA
Range: 1.0–6000.0 s, NP TTT150 = (Hidden)
Time to Trip at 1.75 x FLA
Range: 1.0–6000.0 s, NP TTT175 = (Hidden)
Time to Trip at 2.00 x FLA
Range: 1.0–6000.0 s TTT200 = (Hidden)
Time to Trip at 2.25 x FLA
Range: 1.0–6000.0 s, NP TTT225 = (Hidden)
Time to Trip at 2.50 x FLA
Range: 1.0–6000.0 s TTT250 = (Hidden)
Time to Trip at 2.75 x FLA
Range: 1.0–6000.0 s, NP TTT275 = (Hidden)
Time to Trip at 3.00 x FLA
Range: 1.0–6000.0 s, NP TTT300 = (Hidden)
Time to Trip at 3.50 x FLA
Range: 1.0–6000.0 s, NP TTT350 = (Hidden)
Time to Trip at 4.00 x FLA
Range: 1.0–6000.0 s, NP TTT400 = (Hidden)
Time to Trip at 4.50 x FLA
Range: 1.0–6000.0 s, NP TTT450 = (Hidden)
Time to Trip at 5.00 x FLA
Range: 1.0–600.0 s, NP TTT500 = (Hidden)
Time to Trip at 5.50 x FLA
Range: 1.0–600.0 s TTT550 = (Hidden)
Time to Trip at 6.00 x FLA
Range: 1.0–600.0 s TTT600 = (Hidden)
Time to Trip at 6.50 x FLA
Range: 1.0–600.0 s TTT650 = (Hidden)
Time to Trip at 7.00 x FLA
Range: 1.0–400.0 s TTT700 = (Hidden)
Time to Trip at 7.50 x FLA
Range: 1.0–450.0 s, NP TTT750 = (Hidden)
Time to Trip at 8.00 x FLA
Range: 1.0–400.0 s, NP TTT800 = (Hidden)
Time to Trip at 8.50 x FLA
Range: 1.0–350.0 s, NP TTT850 = (Hidden)
Time to Trip at 9.00 x FLA
Range: 1.0–300.0 s, NP TTT900 = (Hidden)
Time to Trip at 10.00 x FLA
Range: 1.0–225.0 s, NP TTT1000 = (Hidden)
Page 3 of 17
