701 Motor Protection Relay Date Code 20010719
Date ___________
Created by ___________
Factory Defaults
The balance of Thermal Element
Settings are used regardless of setting method.
Thermal Capacity Alarm Pickup
Range: 50%–100% TCAPU = 90
Thermal Capacity Used to Start
Range: 20%–100% TCSTART = 85
Use Learned Starting Thermal Capacity
Range: Y, N TCLRNEN = Y
Motor Stopped Cooling Time
Range: 180–72000 s COOLTIME = 259
Use Learned Cooling Time
(Hidden when RTDOPT = NONE)
Range: Y, N COOLEN = Y
Overcurrent (O/C) Elements
(Time-delay settings are hidden when their associated pickup settings = OFF)
Level 1 Phase O/C Pickup
Range: OFF, 0.25–100.00 A; ITAP = 5 A
OFF, 0.05–20.00 A; ITAP = 1 A
50P1P = OFF
Level 1 Phase O/C Time Delay
Range: 0.00–400.00 s 50P1D = (Hidden)
Level 2 Phase O/C Pickup
Range: OFF, 0.25–100.00 A; ITAP = 5 A
OFF, 0.05–20.00 A; ITAP = 1 A
50P2P = OFF
Level 2 Phase O/C Time Delay
Range: 0.00–400.00 s 50P2D = (Hidden)
Level 1 Residual O/C Pickup
Range: OFF, 0.25–100.00 A; ITAP = 5 A
OFF, 0.05–20.00 A; ITAP = 1 A
50G1P = 2.50
Level 1 Residual O/C Time Delay
Range: 0.00–400.00 s 50G1D = 0.10
Level 2 Residual O/C Pickup
Range: OFF, 0.25–100.00 A; ITAP = 5 A
OFF, 0.05–20.00 A; ITAP = 1 A
50G2P = OFF
Level 2 Residual O/C Time Delay
Range: 0.00–400.00 s 50G2D = (Hidden)
Level 1 Neutral O/C Pickup
Range: OFF, 0.025–10.000 A; INTAP = 5A
OFF, 0.005–2.000 A; INTAP = 1 A
50N1P = 2.500
Level 1 Neutral O/C Time Delay
Range: 0.00–400.00 s 50N1D = 0.10
Level 2 Neutral O/C Pickup
Range: OFF, 0.025–10.000 A; INTAP = 5 A
OFF, 0.005–2.000 A; INTAP = 1 A
50N2P = OFF
Page 4 of 17
