Schweitzer Engineering Laboratories SEL-701 - Page 396

701 Motor Protection Relay Date Code 20010719
Date ___________
Created by ___________
Factory Defaults
Load-Loss Starting Time Delay
Range: 0–15000 s LLSDLY = 0
Load-Loss Alarm Time Delay
Range: 0.00–400.00 s LLADLY = 5.00
Load-Loss Trip Time Delay
Range: 0.00–400.00 s LLTDLY = 10.00
Current Unbalance Elements Settings
Current Unbalance Alarm Pickup
Range: OFF, 2%–80% 46UBA = 10
Current Unbalance Alarm Delay
Range: 0.10–400.00 s 46UBAD = 10.00
Current Unbalance Trip Pickup
Range: OFF, 2%–80% 46UBT = 15
Current Unbalance Trip Delay
Range: 0.10–400.00 s 46UBTD = 5.00
Phase Reversal Tripping Setting
Enable Phase Reversal Tripping
Range: Y, N E47T = Y
Speed Switch Tripping Time Delay Setting
Speed Switch Trip Time Delay
Range: OFF, 0.50–400.00 s SPDSDLY = OFF
RTD Configuration Settings
RTD Input Option (INT is not available if no RTD option)
Range: INT, EXT, NONE RTDOPT = None
Temperature Preference Setting
(Hidden when RTDOPT = NONE)
Range: C, F TMPREF = (Hidden)
RTD Location Settings (Hidden when RTDOPT = NONE)
RTD Location
Range: WDG, BRG, AMB, OTH, NONE RTD1LOC = (Hidden)
RTD Location
Range: WDG, BRG, AMB, OTH, NONE RTD2LOC = (Hidden)
RTD Location
Range: WDG, BRG, AMB, OTH, NONE RTD3LOC = (Hidden)
RTD Location
Range: WDG, BRG, AMB, OTH, NONE RTD4LOC = (Hidden)
Page 6 of 17
