Schweitzer Engineering Laboratories SEL-701 - Page 397

Date Code 20010719 701 Motor Protection Relay
Date ___________
Created by ___________
Factory Defaults
RTD Location
Range: WDG, BRG, AMB, OTH, NONE RTD5LOC = (Hidden)
RTD Location
Range: WDG, BRG, AMB, OTH, NONE RTD6LOC = (Hidden)
RTD Location
Range: WDG, BRG, AMB, OTH, NONE RTD7LOC = (Hidden)
RTD Location
Range: WDG, BRG, AMB, OTH, NONE RTD8LOC = (Hidden)
RTD Location
Range: WDG, BRG, AMB, OTH, NONE RTD9LOC = (Hidden)
RTD Location
Range: WDG, BRG, AMB, OTH, NONE RTD10LOC = (Hidden)
RTD Location
Range: WDG, BRG, AMB, OTH, NONE RTD11LOC = (Hidden)
RTD Location
(Hidden when RTDOPT = INT)
Range: WDG, BRG, AMB, OTH, NONE RTD12LOC = (Hidden)
RTD Type Settings (Hidden when RTDOPT = NONE)
RTD Type
Range: PT100, NI100, NI120, CU10 RTD1TY = (Hidden)
RTD Type
Range: PT100, NI100, NI120, CU10 RTD2TY = (Hidden)
RTD Type
Range: PT100, NI100, NI120, CU10 RTD3TY = (Hidden)
RTD Type
Range: PT100, NI100, NI120, CU10 RTD4TY = (Hidden)
RTD Type
Range: PT100, NI100, NI120, CU10 RTD5TY = (Hidden)
RTD Type
Range: PT100, NI100, NI120, CU10 RTD6TY = (Hidden)
RTD Type
Range: PT100, NI100, NI120, CU10 RTD7TY = (Hidden)
RTD Type
Range: PT100, NI100, NI120, CU10 RTD8TY = (Hidden)
RTD Type
Range: PT100, NI100, NI120, CU10 RTD9TY = (Hidden)
RTD Type
Range: PT100, NI100, NI120, CU10 RTD10TY = (Hidden)
Page 7 of 17
