Schweitzer Engineering Laboratories SEL-701 - Page 398

701 Motor Protection Relay Date Code 20010719
Date ___________
Created by ___________
Factory Defaults
RTD Type
Range: PT100, NI100, NI120, CU10 RTD11TY = (Hidden)
RTD Type
(Hidden when RTDOPT = INT)
Range: PT100, NI100, NI120, CU10 RTD12TY = (Hidden)
RTD Temperature Settings
(Hidden when RTDOPT = NONE)
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP1 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP1 = (Hidden)
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP2 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP2 = (Hidden)
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP3 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP3 = (Hidden)
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP4 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP4 = (Hidden)
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP5 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP5 = (Hidden)
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP6 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP6 = (Hidden)
Page 8 of 17
